4.2 Test
In RF (PC/SC) tap, the read & write to the contactless smartcard can be done.
“Init” is the command to show the installed PC/SC type reader. The available reader will be shown to the left full
down control. “Contact” is the command for the connection to the contactless smartcard and “Reset” is the
disconnection.
After “Contact”, “Get UID”, “Read”, “Write” and “Clear” can be executed. “Get UID” is the reading command for RF
chip’s serial value. “Read” is also the reading command for the data such as name, address and phone which are
predefined. “Write” is the writing command for name, address and phone.
When read and write to the contactless smartcard using APDU command, you can use the below APDU command.
“Load APDU” is loading of the saved APDU command and “Save APDU” is saving the current displayed APDU
command. “Clear APDU” is clearing. To send the individual APDU command, you just press “Send APDU” which you
want.
To write and read from the contactless smartcard, you have to follow the below procedure.
Card “IN” → Move “from In (-62)” → RF (PC/SC) “Init” → RF (PC/SC) “Contact” → RF (PC/SC) “Write” → RF (PC/SC)
“Read” → RF (PC/SC) “Reset” → Card “OUT”
After select “RF (PC/SC)” in tap, if you press “Batch Start”, the encoding will be repeated. SMART printer have the
internal installed contactless smartcard encoder and external installed contactless smartcard encoder. For the
external contactless smartcard encoder, you can test by not marking “Internal (Batch)” item.
