9.1.2. PMA Control and Status Registers
Table 60. PMA Control and Status Register Map
Name Address Bit Offset Type Description
RX Locked
to Data
Status
0x40080 [0]
read-
only
Check the status of rx_is_lockedtodata
tx_ready
Status
0x40081
[0]
read-
only
Check the status of TX ready from the reset controller
rx_ready
Status
[1]
read-
only
Check the status of RX ready from the reset controller
tx_trans
fer_read
y status
0x40082
[0]
read-
only
Check the status of tx_transfer_ready
rx_trans
fer_read
y status
[1]
read-
only
Check the status of rx_transfer_ready
RX PMA
Interface
Reset
0x400E2
[0]
read-
write
Set the status of rx_pmaif_reset Refer to Resetting Transceiver
Channels for more information.
RX AIB
Reset
[1]
read-
write
Set the status of rx_aib_reset Refer to Resetting Transceiver
Channels for more information.
TX PMA
Interface
Reset
[2]
read-
write
Set the status of tx_pmaif_reset Refer to Resetting Transceiver
Channels for more information.
TX AIB
Reset
[3]
read-
write
Set the status of tx_aib_reset Refer to Resetting Transceiver
Channels for more information.
RX PMA
Interface
Reset
Override
[4]
read-
write
Override selects between soft AVMM and reset controller. Set to 0 for
the reset controller to set the reset and 1 for AVMM register
0x400E2[0] to set the value.
RX AIB
Reset
Override
[5]
read-
write
Override selects between soft AVMM and reset controller. Set to 0 for
the reset controller to set the reset and 1 for AVMM register
0x400E2[1] to set the value.
TX PMA
Interface
Reset
Override
[6]
read-
write
Override selects between soft AVMM and reset controller. Set to 0 for
the reset controller to set the reset and 1 for AVMM register
0x400E2[2] to set the value.
TX AIB
Reset
Override
[7]
read-
write
Override selects between soft AVMM and reset controller. Set to 0 for
the reset controller to set the reset and 1 for AVMM register
0x400E2[3] to set the value.
Configurat
ion Profile
Select
0x40140
[2:0]
read-
write
Set the configuration profile the embedded streamer
Start
Streaming
[7]
read-
write
Set to 1'b1 to start streaming the new configuration profile
Busy
Status Bit
0x40141
[0]
read-
only
Bit is set to:
• 1'b1: streaming is in progress
• 1'b0: streaming is complete
PMA
Configurat
ion
0x40143 [7]
read-
write
Request PMA configuration load
continued...
9. Register Map
UG-20056 | 2019.02.04
Intel
®
Stratix
®
10 E-Tile Transceiver PHY User Guide
Send Feedback
166
