The reset values in this table represents register values after a reset has completed.
Bit Name Description SW Access
HW Access
Protection
Reset
6 uncorr_cw Set when a FEC code word could not be corrected due to too many errors. RO
WO
-
0x0
5 corr_cw Set when a FEC code word had one or more errors that were corrected. RO
WO
-
0x0
4 hi_ser High symbol error rate.
Set when the number of symbol errors in a window of 8192 consecutive codewords
has exceeded 417 with RS528 and 6380 with RS544.
If RSFEC_LANE_CFG.indic_byp = 1, then sync header errors will be generated
towards the PCS layer for a period of 60ms to 75ms.
RO
WO
-
0x0
3 am_5bad RX was locked (and aligned if RSFEC_CORE_CFG.frac = none) but 5 consecutive
alignment/codeword markers were not valid.
Restarts the synchronization.
RO
WO
-
0x0
2 fec_3bad RX was locked (and aligned if RSFEC_CORE_CFG.frac = none) but 3 consecutive FEC
codewords could not be corrected.
Restarts the synchronization.
RO
WO
-
0x0
1 not_locked RX lane not locked.
Not locked to alignment/codeword markers (100GE/128GFC/25GE) or to FEC
codewords (32GFC).
One entry per physical lane, regardless of RSFEC_CORE_CFG.frac.
RO
WO
-
0x0
0 sf Incoming signal fail (transceiver unable to lock to signal).
One entry per physical lane, regardless of RSFEC_CORE_CFG.frac.
RO
WO
-
0x0
9.5.13. rsfec_lane_rx_hold
Register Name
Description Address Addressing Mode
rsfec_lane_rx_hold_0 RS-FEC per lane RX status hold 0x160 32-bits
rsfec_lane_rx_hold_1 0x164
rsfec_lane_rx_hold_2 0x168
rsfec_lane_rx_hold_3 0x16C
The reset values in this table represents register values after a reset has completed.
Bit
Name Description SW Access
HW Access
Protection
Reset
6 uncorr_cw Set when a FEC code word could not be corrected due to too many errors. W1C
W1S
-
0x0
5 corr_cw Set when a FEC code word had one or more errors that were corrected. W1C
W1S
-
0x0
4 hi_ser High symbol error rate. W1C 0x0
continued...
9. Register Map
UG-20056 | 2019.02.04
Send Feedback
Intel
®
Stratix
®
10 E-Tile Transceiver PHY User Guide
201
