f. Read 0x8A[7]. It should be 1.
g. Read 0x8B[0] until it changes to 0.
h. Write 0x8A[7] to 1'b1 to clear the 0x8A[7] value.
Related Information
• PMA Register Map on page 165
• PMA Attribute Codes on page 170
8.2. PRBS Usage Model
The PRBS usage model is comprised of the PRBS pattern generator and verifier
configuration and the hard PRBS error counter configuration. You can use PMA Direct
Mode to implement PRBS (10G/25G) channels.
Different PRBS patterns can be configured using the 0x84, 0x85, 0x86, and 0x87
AVMM addresses. The 0x84 and 0x85 AVMM addresses point to the PRBS pattern
code. The 0x86 and 0x87 AVMM addresses point to the PMA code address 0x02.
Figure 88. Setting PMA Attributes for PRBS Through AVMM Registers
0x00 0x02 0x01 0x25
0x87 0x86 0x85 0x84
7 6 5 4 3 2 1 0
Load RX
PRBSGEN
Load TX
PRBSGEN
7 6 5 4 3 2 1 0
Stop on
error
Reserved
Auto seed
correct
Reseed
on Error
Reserved
PRBS Pattern [2:0]
3’b000 = PRBS7
3’b001 = PRBS9
3’b010 = PRBS11
3’b011 = PRBS15
3’b100 = PRBS23
3’b101 = PRBS31
3’b110 = PRBS13
3’b111 = User
PMA code
address
PMA code
value
0x90
7 0 0 07 7
0x8B 0x8A
Request issue
to PMA:
enable or
disable
Status of
request
made to
PMA[0]
Status of
request
made to
PMA[7]
7 0 07
Table 56. PRBS Control PMA Attribute Code Definition, PMA Attribute Code 0x02, PRBS
Enable
Address Direction Definition
0x84[2:0] input
3'b000: prbs7
3'b001: prbs9
3'b010: prbs11
3'b011: prbs15
3'b100: prbs23
3'b101: prbs31
3'b110: prbs13
continued...
8. Dynamic Reconfiguration Examples
UG-20056 | 2019.02.04
Send Feedback
Intel
®
Stratix
®
10 E-Tile Transceiver PHY User Guide
143
