Intel Stratix 10 - Native PHY IP GUI Details

• PMA Bring Up Flow on page 69
• Loading a PMA Configuration on page 163
8.12.2. Native PHY IP GUI Details
Refer to PMA Adaptation for more details.
For PMA bring-up, refer to the DTF flow in PMA Bring Up Flow. To get optimal
performance from the PMA across dynamic temperature conditions, PMA parameter
tuning is required before initiating receiver initial adaptation and receiver continuous
adaptation.
What follows is the Native PHY IP GUI configuration flow.
8. Dynamic Reconfiguration Examples
UG-20056 | 2019.02.04
Intel
®
Stratix
®
10 E-Tile Transceiver PHY User Guide
Send Feedback
158
