Interroll Drum motor DM series connecting cable
20 Version 2.0 (06/2018) en
Translation of original instruction manual
Installing the connecting cable
During the assembly, ensure that the motor with the shaft end for the connector is installed in the
motor brackets on the correct side.
NOTICE
Improper assembly
Damage to the motor
4 During the assembly, ensure that the grease at the seals is not removed.
4 Protect the socket in the motor and the cable plug against contamination.
Warning notices concerning the installation
CAUTION
Improper assembly
Injury or property damage
4 Observe the safety and warning notices of the Interroll drum motor DM series operating
manual.
4 Before installing the connecting cable, carefully read and observe the information about
assembly and startup of the drum motor.
CAUTION
Risk of tripping due to unwound cable
Do not unwind the cable until you are at the installation site.
CAUTION
Rotating parts and inadvertent startup of the motor
Risk of crushing for fingers
4 Do not reach into areas between drum motor and conveyor belts or roller chains.
4 Install a protection device (such as a guard plate) to prevent fingers from getting trapped in
the chain belts or roller chains.
4 Install an appropriate warning on the conveyor.
