OK/FAIL LED, one bicolor:
•
Steady green–The IOC is operating normally.
•
Red–The IOC has failed and is not operating normally.
•
Off–The IOC is powered down.
LEDs
The serial number label is located as shown in Figure 56 on page 130.
Figure 56: SRX5K-4XGE-XFP Serial Number Label
OK/
F
AIL
TUNNEL
LINK
1/0
TUNNEL
LINK
0/0
TUNNEL
LINK
2/0
TUNNEL
LINK
3/0
g004067
AA567 8
Serial number
ID label
Serial Number Location
SRX5K-IOC4-10G Specifications
SRX5K-IOC4-10G is a fixed-configuration interface card with a Packet Forwarding Engine that provides
400-Gbps line rate. This interface card provides scalability in bandwidth and services to the SRX5400,
SRX5600 and SRX5800 Services Gateways. See Figure 57 on page 131.
NOTE: SRX5K-IOC4-10G cards do not support plug-in Modular Interface Cards (MICs).
130
