SRX5400 Alarm and Management Cable Specifications
and Pinouts
IN THIS SECTION
Alarm Relay Contact Wire Specifications for the SRX5400 Services Gateway | 165
Console Port Cable and Wire Specifications for the SRX5400 Services Gateway | 165
RJ-45 Connector Pinouts for the SRX5400 Services Gateway Routing Engine Ethernet Port | 166
RJ-45 Connector Pinouts for the SRX5400 Services Gateway Routing Engine Auxiliary and Console Ports | 166
Alarm Relay Contact Wire Specifications for the SRX5400 Services Gateway
Table 45 on page 165 lists the specifications for the wires that connect to the alarm relay contacts.
Table 45: Cable and Wire Specifications for Alarm Interfaces
Cable/Wire SuppliedCable SpecificationPort
NoWire with gauge between 28-AWG and 14-AWG (0.08
and 2.08 mm
2
)
Alarm relay contacts
Console Port Cable and Wire Specifications for the SRX5400 Services
Gateway
Table 46 on page 165 lists the specifications for the cable that connects a CONSOLE port on the Routing
Engine to a management console.
Table 46: Cable and Wire Specifications for Routing Engine Management and Alarm Interfaces
Receptacle
Maximum
LengthCable/Wire SuppliedCable SpecificationPort
RJ-45/DB-9
male
6 ft (1.83 m)One 6-ft (1.83-m) length
with RJ-45/DB-9
connectors
RS-232 (EIA-232)
serial cable
Routing Engine
console or auxiliary
interface
