Installing the SRX5400 Services Gateway Using a Mechanical Lift
Because of the services gateway’s size and weight—up to 220 lb (100 kg) depending on the
configuration—we strongly recommend that you install the services gateway using a mechanical lift. If you
do not use a lift to install the services gateway, see “Overview of Installing the SRX5400 Services Gateway
Without a Mechanical Lift” on page 183 for complete instructions to install the services gateway safely.
CAUTION: Before front mounting the services gateway in a rack, have a qualified
technician verify that the rack is strong enough to support the services gateway's
weight and is adequately supported at the installation site.
To install the services gateway using a lift (see Figure 73 on page 182):
1. Ensure that the rack is in its permanent location and is secured to the building. Ensure that the installation
site allows adequate clearance for both airflow and maintenance.
2. Load the services gateway onto the lift, making sure it rests securely on the lift platform.
3. Using the lift, position the services gateway in front of the rack or cabinet, centering it in front of the
mounting shelf.
4. Lift the chassis approximately 0.75 in. above the surface of the mounting shelf and position it as close
as possible to the shelf.
5. Carefully slide the services gateway onto the mounting shelf so that the bottom of the chassis and the
mounting shelf overlap by approximately two inches.
6. Slide the device onto the mounting shelf until the mounting brackets contact the rack rails. The shelf
ensures that the holes in the mounting brackets of the chassis align with the holes in the rack rails.
7. Move the lift away from the rack.
8. Install a mounting screw into each of the open mounting holes aligned with the rack, starting from the
bottom.
9. Visually inspect the alignment of the services gateway. If the services gateway is installed properly in
the rack, all the mounting screws on one side of the rack should be aligned with the mounting screws
on the opposite side and the device should be level.
181

Juniper SRX5400 Specifications

General

Model	SRX5400
New Sessions per Second	200, 000
Operating System	Junos OS
Platform	SRX Series
Interfaces	Multiple 1G, 10G, and 40G interfaces
Power Supply	Dual AC or DC power supplies
