Table 15: AC Power Supply Electrical Specifications
SpecificationItem
1167 W (low line)
2050 W (high line)
Maximum output power
16 A @ 110 VAC maximum
15.1 A @ 200 VAC maximum
AC input current rating
Operating range: 100 - 240 VAC (nominal)AC input voltage
50 to 60 Hz (nominal)AC input line frequency
Table 16: AC Power System Specifications
High-Line (220V)Low-Line (110V)Item
2+12+1Redundancy
2050 W1167 WOutput power (maximum) per power supply
4100 W3501 WOutput power (maximum) per system
SRX5400 Services Gateway AC Power Supply LEDs
Each AC power supply faceplate contains three LEDs that indicate the status of the power supply (see
Table 17 on page 48). The power supply status is also reflected in two LEDs on the craft interface. In
addition, a power supply failure triggers the major alarm LED on the craft interface.
