The serial number label is located as shown in Figure 27 on page 77.
Figure 27: SRX5K-RE-1800X4 Serial Number Label
Serial number location
SRX5K-RE-1800X4 LEDs
Each Routing Engine has four LEDs that indicate its status. The LEDs, labeled MASTER, STORAGE, ONLINE,
and OK/FAIL, are located directly on the faceplate of the Routing Engine. Table 26 on page 77 describes
the Routing Engine LEDs and their states.
Table 26: SRX5K-RE-1800X4 LEDs
DescriptionStateColorLabel
Routing Engine is the master.On steadilyBlueMASTER
Indicates activity on the SSD or
CompactFlash card.
BlinkingGreenSTORAGE
Routing Engine is transitioning
online.
BlinkingGreenONLINE
Routing Engine is functioning
normally.
On steadilyNone
Routing Engine has failed.On steadilyRedOK/FAIL
