WARNING: For field-wiring connections, use copper conductors only.
CAUTION: Power cords and cables must not block access to device components or
drape where people could trip on them.
SRX5400 Services Gateway Chassis Grounding Point Specifications
WARNING: To meet safety and electromagnetic interference (EMI) requirements and
to ensure proper operation, you must properly ground the services gateway chassis
before connecting power. See “Grounding the SRX5400 Services Gateway” on page 199
for instructions.
CAUTION: Before services gateway installation begins, a licensed electrician must
attach cable lugs to the grounding and power cables that you supply. A cable with an
incorrectly attached lug can damage the services gateway.
The services gateway chassis has one grounding point at the upper right corner of the back panel. The
grounding point consists of two threaded holes spaced 0.625-in. (15.86-mm) apart (Figure 14 on page 57).
The grounding point holes fit UNC 1/4–20 screws. The accessory box shipped with the services gateway
includes the cable lug that attaches to the grounding cable and two UNC 1/4–20 screws used to secure
the grounding cable to the services gateway grounding point.
56
