The serial number label is located as shown in Figure 66 on page 142.
Figure 66: Port Module SRX-IOC-16GE-TX Serial Number Label
g030305
JX0123
Serial number
ID label
Serial Number Location
Flex I/O Card Port Module SRX-IOC-4XGE-XFP Specifications
You use port modules and Flex I/O Cards (Flex IOCs) to add different combinations of small form-factor
pluggable transceiver (SFP), 10-gigabit SFP transceiver (XFP), and copper ports to your services gateway
to suit the specific needs of your network. The SRX-IOC-4XGE-XFP port module (Figure 67 on page 142)
installs into a Flex IOC to add four 10-Gigabit Ethernet XFP ports.
Figure 67: Flex IOC Port Module SRX-IOC-4XGE-XFP
g030269
•
Port module with four 10-Gigabit Ethernet XFP ports
•
Maximum throughput: 10 Gbps
•
Oversubscription ratio: 4:1
•
Maximum configurable MTU: 9192 bytes
Description
•
Junos OS Release 9.5R1 and laterSoftware release
