Juniper SRX5400 - Removing the SRX5400 Services Gateway Fan Tray

Removing the SRX5400 Services Gateway Fan Tray
NOTE: To prevent overheating, install the replacement fan tray immediately after removing the
existing fan tray.
To remove the fan tray (see Figure 95 on page 228):
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
2. Loosen the captive screws on the fan tray faceplate.
3. Grasp the fan tray handle and pull it out approximately 1 to 3 inches.
WARNING: To avoid injury, keep tools and your fingers away from the fans as
you slide the fan tray out of the chassis. The fans might still be spinning.
4. Press the latch located on the inside of the fan tray to release it from the chassis.
5. Place one hand under the fan tray to support it and pull the fan tray completely out of the chassis.
Figure 95: Removing the Fan Tray
228
