312 W typical, 365 W maximum (includes port modules)Power Requirement
Approximately 10 lb (4.5 kg)Weight
OK/FAIL LED, one bicolor:
•
Steady green–The Flex IOC is operating normally.
•
Red–The Flex IOC has failed and is not operating normally.
•
Off–The Flex IOC is powered down.
LEDs
The serial number label is located as shown in Figure 62 on page 138.
Figure 62: Serial Number Label (IOC Shown, Other Cards Similar)
OK/
F
AIL
TUNNEL
LINK
1/0
TUNNEL
LINK
0/0
TUNNEL
LINK
2/0
TUNNEL
LINK
3/0
g004067
AA567 8
Serial number
ID label
Serial Number Location
Flex I/O Card Port Module SRX-IOC-16GE-SFP Specifications
You use port modules and Flex I/O Cards (Flex IOCs) to add different combinations of small form-factor
pluggable transceiver (SFP), 10-gigabit SFP transceiver (XFP), and copper ports to your services gateway
to suit the specific needs of your network. The SRX-IOC-16GE-SFP port module (Figure 63 on page 139)
installs into a Flex IOC to add sixteen 10/100/1000 Ethernet SFP ports.
138
