Table 5: Front Panel of the Craft Interface (continued)
ReferenceDescriptionComponent
See “SRX5400 Services Gateway Craft
Interface Card OK/Fail LEDs” on page 36
See “SRX5400 Services Gateway Craft
Interface Online/Offline Buttons” on
page 37
SCB and MPC LEDs, and MPC
online/offline buttons
The card LEDs are located along the
bottom edge of the craft interface and are
labeled 0 for the bottom slot reserved for
the SCB and 0/1, 1, and 2 for the
remaining slots.
8/9
NOTE: The SCB must be installed in the services gateway for the craft interface to obtain power.
SRX5400 Services Gateway Craft Interface Alarm LEDs and Alarm
Cutoff/Lamp Test Button
Two large alarm LEDs are located at the upper right of the craft interface. The circular red LED lights to
indicate a major alarm condition that can result in a system shutdown. The triangular yellow LED lights to
indicate a less severe minor alarm condition that requires monitoring or maintenance. Both LEDs can be
lit simultaneously. A condition that causes an LED to light also activates the corresponding alarm relay
contact on the craft interface.
To deactivate the major and minor alarms, press the button labeled ACO/LT (for “alarm cutoff/lamp test”),
which is located to the right of the alarm LEDs. Deactivating an alarm turns off both LEDs and deactivates
the device attached to the corresponding alarm relay contact on the craft interface.
Table 6 on page 35 describes the alarm LEDs and alarm cutoff button in more detail.
34
