Holding an SRX5400 Services Gateway Card
When carrying a card, you can hold it either vertically or horizontally.
NOTE: A card weighs up to 18.3 lb (8.3 kg). Be prepared to accept the full weight of the card
as you lift it.
To hold a card vertically:
1. Orient the card so that the faceplate faces you. To verify orientation, confirm that the text on the card
is right-side up and the EMI strip is on the right-hand side.
2. Place one hand around the card faceplate about a quarter of the way down from the top edge. To avoid
deforming the EMI shielding strip, do not press hard on it.
3. Place your other hand at the bottom edge of the card.
If the card is horizontal before you grasp it, place your left hand around the faceplate and your right hand
along the bottom edge.
To hold a card horizontally:
1. Orient the card so that the faceplate faces you.
2. Grasp the top edge with your left hand and the bottom edge with your right hand.
You can rest the faceplate of the card against your body as you carry it.
As you carry the card, do not bump it against anything. Card components are fragile.
Never hold or grasp the card anywhere except those places that this topic indicates are appropriate. In
particular, never grasp the connector edge, especially at the power connector in the corner where the
connector and bottom edges meet (see Figure 110 on page 279).
278
