Installing the SRX5400 Services Gateway Chassis in the Rack Manually
To install the device in the rack (see Figure 77 on page 189):
CAUTION: If you are installing more than one services gateway in a rack, install the
lowest one first. Installing a services gateway in an upper position in a rack or cabinet
requires a lift.
CAUTION: Before front mounting the services gateway in a rack, have a qualified
technician verify that the rack is strong enough to support the services gateway’s
weight and is adequately supported at the installation site.
CAUTION: Lifting the chassis and mounting it in a rack requires two people. The empty
chassis weighs approximately 65 lb (29 kg).
1. Ensure that the rack is in its permanent location and is secured to the building. Ensure that the installation
site allows adequate clearance for both airflow and maintenance.
2. Position the services gateway in front of the rack or cabinet, centering it in front of the mounting shelf.
Use a pallet jack if one is available.
3. With one person on each side, hold onto the bottom of the chassis and carefully lift it onto the mounting
shelf.
WARNING: To prevent injury, keep your back straight and lift with your legs,
not your back. Avoid twisting your body as you lift. Balance the load evenly and
be sure that your footing is solid.
4. Slide the services gateway onto the mounting shelf until the mounting brackets contact the rack rails.
The shelf ensures that the holes in the mounting brackets of the chassis align with the holes in the rack
rails.
