5. Install a mounting screw into each of the open mounting holes aligned with the rack, starting from the
bottom.
6. Visually inspect the alignment of the services gateway. If the services gateway is installed properly in
the rack, all the mounting screws on one side of the rack should be aligned with the mounting screws
on the opposite side and the services gateway should be level.
Figure 77: Installing the Services Gateway in the Rack
NOTE: This illustration depicts the services gateway being installed in an open-frame rack.
189
