Table 48: RJ-45 Connector Pinout for the AUX and CONSOLE Ports (continued)
DescriptionSignalPin
Data Terminal ReadyDTR2
Transmit DataTXD3
Signal GroundGround4
Signal GroundGround5
Receive DataRXD6
Data Set ReadyDSR/DCD7
Clear to SendCTS8
RELATED DOCUMENTATION
Connecting the SRX5400 to External Devices | 193
