user@host> show chassis environment pem
PEM 0 status:
State Online
Temperature OK
DC Input: OK
DC Output Voltage(V) Current(A) Power(W) Load(%)
52 8 416 17
Voltage:
48.0 V input 52000 mV
PEM 1 status:
State Empty
PEM 2 status:
State Online
Temperature OK
DC Input: OK
DC Output Voltage(V) Current(A) Power(W) Load(%)
53 10 530 21
Voltage:
48.0 V input 53000 mV
PEM 3 status:
State Empty
Make sure that the power and grounding cables are arranged so that they do not obstruct access to
other services gateway components.
Routinely check the status LEDs on the power supply faceplates and the craft interface to determine if
the power supplies are functioning normally.
Check the red and yellow alarm LEDs on the craft interface. Power supply failure or removal triggers an
alarm that causes one or both of the LEDs to light. You can display the associated error messages by
issuing the following command:
user@host> show chassis alarms
Periodically inspect the site to ensure that the grounding and power cables connected to the device are
securely in place and that there is no moisture accumulating near the device.
