CAUTION: Avoid bending a fiber-optic cable beyond its minimum bend radius.
An arc smaller than a few inches in diameter can damage the cable and cause
problems that are difficult to diagnose.
13. Connect the power cables to the chassis.
14. Power on the services gateway. The OK LED on the power supply faceplate should blink, then light
steadily.
15. Verify that the SPC is functioning correctly by issuing the show chassis fpc and show chassis fpc
pic-status commands.
Figure 117: Installing an SPC
Figure 118: Attaching a Cable to an SPC
g030335
Fiber-optic
cable connector
299
