Keyscan Technical Guide (PC109x - 04.12)
121
Reader Power Notes
HID iClass KEYR40
(HID label – 6120AKN0010 – Rev A)
12 VDC, 260 mA See note HID iClass KEYR10 – Rev A
HID iClass KEYRK40
(HID label – 6130AKN001000 – Rev A)
12 VDC, 260 mA See note HID iClass KEYR10 – Rev A
HID iClass KEYRW400
(HID label 6121AKN0010 – Rev A)
12 VDC, 260 mA See note HID iClass KEYR10 – Rev A
HID iClass – Rev B
HID iClass KEYR10 12 VDC, 75 mA (HID label – 6100BKN0010 – Rev B)
HID iClass KEYR40 12 VDC, 75 mA (HID label – 6120BKN0010 – Rev B)
HID iClass – Rev C (Current
Rev)
HID iClass KEYR10 12 VDC, 116 mA (HID label – 6100CKN0010 – Rev C)
HID iClass KEYR40 12 VDC, 121 mA (HID label – 6120CKN0010 – Rev C)
HID iClass KEYRK40 12 VDC, 130 mA (HID label - 6130CKN001000 – Rev C)
HID iClass KEYRW400 12 VDC, 121 mA (HID label – 6136CKT001000 – Rev C)
Installation Notes on Proximity Readers
Do not run reader cables in same conduit with AC power or signal cables. Keep reader cables at least 12 inches
or 30 centimetres from AC, computer data, telephone data, or electric lock device cables. Do not install
readers within 3.5 feet or 1.1 metres of computer CRTs. Do not install readers where broad spectrum EMI
noise may be present. Motors, pumps, generators, and AC switching relays can create EMI noise. Readers
mounted on a metal surface can have reduced read ranges. See HID manual for operational details and
recommendations. The following diagrams illustrate HID readers with dual LEDs. On models 5365, 5395, and
6005 do not use the brown wire with "00" LED. If readers are single LED type "06", substitute the brown wire
in place of the orange wire.
• S16 – 5 ON dual LED = 00
• S16 – 5 OFF single LED = 06
C1 Beep
When the pre-alert wire is connected to C1 (Beep) on the reader terminal, the reader will also sound on
an “alarm tripped”.
