Keyscan EC2500 Series User Manual

Keyscan Technical Guide (PC109x - 04.12)
80
Figure 57 – Single ACU Communication - NETCOM2P or NETCOM6P/CB-485
-PC
- 10/100 Base-T Cable
- Control Board
- CB-485
- NETCOM2P or NETCOM6P
GND
J1
TD
RD
NC
Jumper ON J1
to network
to network
Host PC with
Communication
Manager
10 or 100 Base-T
Current Draw
250 mA
Jumpers
ON
Run
Run
Program
Parts List
Connect CB-485 ribbon cable to
CPB/CB MODULE on control board.
Jumper ON J16-G to activate
CPB/CB MODULE (H1) with
CB-485/ NETCOMP.
Control Board
(PC 109x)
Common AUX Inputs - E
24
2322
2120191817
CPB/CB MODULE
(COM4)
H1
SYSTEM CONFIG.
J16 - HGABCDEF
BRN WHT GRN WHT BRN WHTGRN WHT BLU WHT
RS485 IN RS485 OUT M
+-+- +-+-
CB-485
RX
LED
TX
LED
ECM/GCM MODULE
(COM2 & COM3)
H2
KI-00160E-07-11
