Keyscan EC2500 Series User Manual

Keyscan Technical Guide (PC109x - 04.12)
44
Terminate Elevator Floor Wiring
If the elevator control board regulates more than 8 floors, multiple output control boards (OCB-8) are required.
See the following table for ribbon cable elevator/floor assignments from the OCB-8 terminal to the elevator
control board terminal.
OCB-8 Jumper Settings
• J1 to J8 set to Reversed position
• J9 set to EXT PWR
Note
Verify all floor hardware conforms to federal, state, provincial or municipal fire codes.
Table 4 – OCB-8 to EC1500B Ribbon Cable Connections
OCB Terminal Elevator Control Board
Terminal
Elevator Floors
1
st
OCB-8 – H1 Control 1 1 1 – 8
*2
nd
OCB-8 – H1 Control 2 1 9 – 16
*3
rd
OCB-8 – H1 Control 3 1 17 – 24
*4
th
OCB-8 – H1 Control 4 1 25 – 32
*5
th
OCB-8 – H1 Control 5 1 33 – 40
Table 5 – OCB-8 to EC2500B Ribbon Cable Connections
OCB Terminal Elevator Control Board Terminal Elevator Reader Floors
1
st
OCB-8 – H1 Control 1 1 1 1 – 8
*2
nd
OCB-8 – H1 Control 2 1 1 9 – 16
3
rd
OCB-8 – H1 Control 3 2 2 1 – 8
*4
th
OCB-8 – H1 Control 4 2 2 9 – 16
* Optional OCB-8's must be purchased separately.
