Keyscan Technical Guide (PC109x - 04.12)
29
Door Lock Hardware
Consult with the manufacturer's documentation for mounting door lock hardware.
The lock must be appropriate for the barrier and meet all applicable fire and safety codes. If necessary, consult
with local officials such as the fire department to ensure the installation conforms to municipal, state, or
provincial safety regulations. Permits may be required before installing magnetic locks.
Use a battery for temporary power to ensure the door operates properly – alignment, holding, activation, de-
activation – before connecting to the Keyscan access control unit.
Figure 17 – Typical Door Strike Connection
+
KI-00120E-07-11
Figure 18 – Typical Magnetic Lock Connection
KI-00121E-07-11
