Keyscan Technical Guide (PC109x - 04.12)
120
Appendix A – Keyscan /
HID Readers
Appendix A reviews typical connections for Keyscan and HID readers. Wiring diagrams are on the following
pages. Refer to the appropriate diagram for specific reader connections. Be sure to use a cable that complies
with the reader’s wiring specifications.
Power Specifications
The following table outlines HID reader power specifications:
Table 19 – Keyscan & HID Reader Power Specifications
Reader Power Notes
K-PROX2 & K-PROX SG(125 KHz HID
compatible)
12 VDC, 80 mA
K-VAN 12 VDC, 90 mA
K-KPR 12 VDC, 115 mA
K-SMART (13.56 MHz) 12 VDC, 210 mA
K-SMART – 125 12 VDC, 210 mA
K-SMART GOV 12 VDC, 210 mA
K-SMART GOV/125 12 VDC, 210 mA
K-KPR-SM Mifare 12 VDC, 220 mA
K-KPR-SM/125 12 VDC, 220 mA
K-KPR-GOV 12 VDC, 220 mA
K-KPR-G/125 12 VDC, 220 mA
HID-5365 12 VDC, 75 mA
HID-5395 12 VDC, 115 mA
HID-6005 12 VDC, 75 mA
HID-5455 12 VDC, 125 mA
HID-5355KP 12 VDC, 120 mA
HID 5375 24 VDC, 1.5 A Requires 18 AWG cable. Connect to separate 24 VDC 2
Amp linear power supply. (Not supplied with ACU)
HID iClass – Rev A
HID iClass KEYR10
(HID label – 6100AKN0010 – Rev A)
12 VDC, 225 mA Connect to separate 12 VDC 4 Amp linear power supply
(not supplied with ACU kit) for CA 8000 when
connecting 8 readers. For all other models connect
power (red) of iClass reader directly to DPS-15 power.
