Keyscan EC2500 Series User Manual

Keyscan Technical Guide (PC109x - 04.12)
75
Figure 52 – Single ACU Communication - Serial CPB-10-2
to Com Port
RS-232
22 AWG shielded cable
Maximum - 100 ft (30 m)
Brown Shield Green Black Red White
PC with
Communication
Manager
- RS-232 Data Cable
- Control Board
-CPB-10-2
- PC (requires serial port)
GND
Brown & White not
used and taped back.
Green Red
CPB-10-2
J1
Black
Control Board
(PC 109x)
RX LEDTX LED
TD RD DCD GND R T B DTR CTS
Jumper ON J1
Current Draw - 40 mA
Shield*
to ground lug
Common AUX Inputs - E
24
2322
2120191817
CPB/CB MODULE
(COM4)
Parts List
Connect CPB-10-2
ribbon cable to CPB/CB
MODULE on control
board.
Jumper ON J16-G to
activate CPB/CB
MODULE (H1).
SYSTEM CONFIG.
J16 - HGABCDEF
H1
ECM/GCM MODULE
(COM2 & COM3)
H2
KI-00155E-07-11
* Insulate shield with PVC tubing such
as Alpha #16 or comparable insulator
and connect to ground lug.
