Keyscan EC2500 Series User Manual

Keyscan Technical Guide (PC109x - 04.12)
60
Ref
#
Reader Format Security
Level
Settings
Pins 6 - 1
Card Number
Format
Notes
L FIPS/TWIC – 75-bit output (48-
bit FASC-N, 25-bit expiration
date, 2 parity bits) & Keyscan
36-bit
High 1 0 1 0 0 1 Extended
M FIPS/TWIC – 75-bit output (48-
bit FASC-N, 25-bit expiration
date, 2 parity bits) & Keyscan
36-bit & Mifare – 40-bit CSN
(32-bit CSN, 8-bit Checksum)
High 1 0 1 0 1 0 Extended
The following Reader Formats Ref # 1 – 31 are NOT recommended.
1 Standard 26-bit & Keyscan 36-
bit
Low 0 0 0 0 0 1 Standard
2 Northern 34-bit, Standard 26-
bit & Keyscan 36-bit
Low 0 0 0 0 1 0 Standard
3 Corby 30-bit & Keyscan 36-bit Medium 0 0 0 0 1 1 Standard
4 Kantech 32-bit & Keyscan 36-bit Medium 0 0 0 1 0 0 Standard
5 DSX 33-bit & Keyscan 36-bit Medium 0 0 0 1 0 1 Standard
6 Intercon 32-bit & Keyscan 36-
bit
Low 0 0 0 1 1 0 Standard
7 Chubb 36-bit (5 & 6 digit cards)
& Keyscan 36-bit
Low 0 0 0 1 1 1 Standard
8 Keyscan 36-bit with zero batch
number
Low 0 0 1 0 0 0 Standard - except
Facility Code = 0
Enter 0 (zero) for the
facility code in the Client
software to ignore the
FC output from the
reading device.
9 Standard 26-bit & Keyscan 36-
bit
Low 0 0 1 0 0 1 Standard – except
for 26-bit cards
Facility Code = 0
Enter 0 (zero) for the
facility code in the Client
software to ignore the
FC output from the
reading device.
10 Northern 34-bit & Keyscan 36-
bit
Low 0 0 1 0 1 0 Standard – except
for 34-bit cards
Facility Code = 0
Enter 0 (zero) for the
facility code in the Client
software to ignore the
FC output from the
reading device.
11 Corby 30-bit & Keyscan 36-bit Low 0 0 1 0 1 1 Standard - except
for 30-bit cards
Facility Code = 0
Enter 0 (zero) for the
facility code in the Client
software to ignore the
FC output from the
reading device.
12 GE 40-bit or Casi-Rusco Ex.
Prox-Lite 941-W RDR
Low 0 0 1 1 0 0 Standard
13 Keyscan 36-bit & 37-bit (37 Bit
Corp H10302)
Low 0 0 1 1 0 1 Standard
14 Keyscan England 36-bit with no
manufacturer's code check
Low 0 0 1 1 1 0 Standard Format does not support
Keyscan WSSKP-1
Keypad with PIN use.
15 Legacy HID 35-bit & Keyscan
36-bit
Low 0 0 1 1 1 1 Standard – except
for HID 35-bit
cards - Company
ID Code ignored.
See Reader Format –
Ref # C – preferred
option.
16 HID Computrol 34-bit &
Keyscan 36-bit
Medium 0 1 0 0 0 0 Standard
