Handler Interface
Functional Description
When equipped with Option 201 Handler Interface, the E4980A/AL can
interact with the handler. The 36-contact Amphenol connector on the rear
panel is used to connect the interface, through which control input/output
signals and comparator bin sorting result signals are communicated.
For more information on available options, see Appendix E , “Handler
Interface,” on page 465
.
When the E4980A/AL is not equipped with the Handler Interface, the
HANDLER I/F field shows a “NOT INSTALLED” message and the ON/OFF
settings are not available.
Softkey Description
ON Turns ON the handler interface feature.
OFF Turns OFF the handler interface feature.
