-476 Keysight E4980A/AL User’s Guide
Handler Interface
Signal Line Definitions
-
Figure E-5 Timing chart (for the list sweep comparator)
Table E-6 Time segments in the time chart
Time segment Minimum value
Typical
1
T1 Trigger pulse width 1 sec -
T2 /INDEX and /EOM response time of measurement time 0 Sec 350 msec
