182
Sequencer operating mode
Event Edit: Event Edit
And here are the events contained in the Master track.
To edit the event Type and Values, select the parameter and use
the TEMPO/VALUE controls to change their value. In case of
numeric values, you can also press them twice to open the
numeric keypad.
Length
Length of the selected Note event. The value format is the same
as the Position value. Edit it in the same way.
Note: If you change a length of “000.00.000” to a different value,
you can’t go back to the original value. This rather uncommon
zero-length value may be found in the drum and percussion tracks
of Songs made in Backing Sequence mode.
Track
Use this pop-up menu to select the track to edit.
Track 1…16 One of the ordinary tracks of the Song. These
tracks contains musical data, like notes and con-
trollers.
Master This is a special track, containing Tempo changes,
Meter changes, Scale and Transpose data, and the
effect parameters.
Scrollbar
Use the scrollbar to browse the event through the list. You can
also scroll by using the SHIFT + DIAL combination.
Go/Catch
This is a dual-function command.
• While the sequencer is not running, it works as a Go to Mea-
sure command. Press it to open the Go to Measure dialog box:
When in this dialog box, select a target measure, and press OK.
The first event available in the target measure will be selected.
• While the sequencer is running, it works as a Catch Locator
command. Press it to show the event that is currently playing.
Insert
Press the Insert button in the display to insert a new event at the
current shown Position. The default values are Type = Note,
Pitch = C4, Velocity = 100, Length = 192.
Note: You can’t insert new events in an empty, non-recorded Song.
To insert an event, you must first insert some empty measures by
using the Insert Measure function (see “Song Edit: Cut/Insert Mea-
sures” on page 185).
Delete
Press the Delete button in the display to delete the event selected
in the display.
Note: The “End of Track” event cannot be deleted.
Event Edit procedure
Here is the general event editing procedure.
1. While in the Event Edit page, press (PLAY/STOP) in the
SEQUENCER 1 section to listen to the Song. Press it again
to stop the Song.
2. Select the Filter page, and turn “Off” the filter for the event
types you wish to see in the display (see “Event Edit: Filter”
on page 183 for more information).
3. Return to the Event Edit page.
4. Use the “Track” pop-up menu to select the track to edit.
The list of events contained in the selected track will appear
in the display.
For more information on the event types and their val-
ues, see above.
5. Select the “Position” parameter. Use the TEMPO/VALUE
controls (or press the parameter again to open the numeric
keypad) to change the event’s position.
6. Select the “Type” parameter and use the TEMPO/VALUE
controls to change the event type. Select the “Value 1 and
2” parameters and use the TEMPO/VALUE controls (or
press the parameter again to open the numeric keypad) to
modify the selected value.
7. In the case of a Note event, select the Length parameter,
and use the TEMPO/VALUE controls (or press the parame-
ter again to open the numeric keypad) to change the event’s
length.
• While the sequencer is not running, you may press the
Go/Catch button in the display to go to a different measure
(see “Go/Catch” above)
PAft Note to which the After-
touch is applied
Poly Aftertouch value
Type First value Second value
Tempo Tempo change –
Volume Master Volume value –
Meter
Meter change
(a)
(a). Meter changes can’t be edited or inserted separately from a mea-
sure. To insert a Meter change, use the Insert function in the Edit sec-
tion and insert a series of measures with the new meter. Existing data
can then be copied or entered to these measures
–
Scale One of the available pre-
set Scales
Root note for the
selected Scale
UScale (User Scale) Altered note
Note alteration
(b)
(b). To edit User Scale and Quarter Tone settings, select the first value,
then select the scale’s degree to edit. Edit the second value to change
the tuning of the selected note of the scale.
QT (Quarter Tone) Altered note Note alteration
(0, 50)
(b)
QT Clear (Quarter
Tone Clearing)
Reset of all Quarter Tone
(QT) changes
–
FXType One of the four available
FX processors
Effect number
(c)
(c). When selecting a different effect number during this edit, default
settings will be assigned to this event.
FXSend Feedback Send (B>A or
D>C)
Feedback send
level
Type First value Second value
