FlexLine plus, Programs
67
Access
Stakeout Settings
1. Select Programs from the Main Menu.
2. Select Stakeout from the Programs Menu.
3. Complete program pre-settings. Refer to "6 Programs - Getting Started".
Field Description
Pre-/Suffix
Only used for the Stakeout program.
Prefix Adds the character entered for Identifier in front of
the original point number of the point to be staked.
Suffix Adds the character entered for Identifier at the end
of the original point number of the point to be
staked.
Off The staked point is stored with the same point
number as the point to be staked.
Identifier
Only used for the Stakeout program.
The identifier can be up to four characters and is added at the start,
or end, of a point number of a point to be staked.
Stakeout Beep On The instrument beeps when the distance from the
current position to the point to be staked is 0.5 m.
The closer the prism is to the point to be staked the
faster the beeps will be.
Off Beep is deactivated.
Filter Off No filter is active
Nearest Searches the job for points close to the current posi-
tion. The points are selected as the points to be
staked. After staking and storing the first nearest
point, the next nearest point is suggested for
staking out.
The program algorithm sorts the points according to
the minimum walking distance in all directions to
each point.
Radius Shows points within the defined radius from a
particular point. The radius is the horizontal
distance.
PtId Range Shows points with point IDs between the entered
start and end ID.
Center Point The point to which the radius is applied.
Radius The radius of the circle within which the points are shown.
From The first point to be displayed.
To The last point to be displayed.
