237
PCP value in the tag. Otherwise the frame is classified to the default PCP value.
DEI :
Controls the default DEI value.
All frames are classified to a DEI value.
If the port is VLAN aware and the frame is tagged, then the frame is classified to the
DEI value in the tag. Otherwise the frame is classified to the default DEI value.
Tag Class. :
Shows the classification mode for tagged frames on this port.
Disabled: Use default QoS class and DP level for tagged frames.
Enabled: Use mapped versions of PCP and DEI for tagged frames.
Click on the mode in order to configure the mode and/or mapping.
NOTE: This setting has no effect if the port is VLAN unaware.
Tagged frames received on VLAN unaware ports are always
classified to the default CoS and DPL.
DSCP Based :
Click to Enable DSCP Based QoS Ingress Port Classification.
Address Mode :
The IP/MAC address mode specifying whether the QCL classification must be based
on source (SMAC/SIP) or destination (DMAC/DIP) addresses on this port. The
allowed values are:
Source: Enable SMAC/SIP matching.
Destination: Enable DMAC/DIP matching.
Buttons:
Apply – Click to save changes.
Reset- Click to undo any changes made locally and revert to previously saved
values.
