LIP-8040L User Guide
4
1.5.1 Power
All LIP-80
00 series phones can be powered by the
AC/DC Adapter-K- (48 VDC @0.3A; shown “C” in
previous graphic) or over the LAN cable using the POE8
or other 802.3af compliant switch.
If using the AC/DC Adapter, after connecting the Phone
to the LAN, the Adapter’s DC voltage plug is inserted
into the power-input jack in the underside of the Phone.
One end of the AC power cord is inserted into the
mating receptacle of the AC Adapter, and the other end
is inserted into the AC power outlet.
NOTE—LIP-8000 series consoles are powered through
the flat cable used to connect the console to the IP
phone (shown). Up to 2(without LIP-8048DSS) or
4(with LIP-8048DSS) consoles can be chain-link
connected to the phone. DSS Connection to IP Phone
1.5.2 Wall Mount
T
he LIP-8000 series phones can be wall mounted as
needed. The following instructions describe how to
perform a wall mount installation. For more detailed
instruction, refer to the iPECS Hardware Description
and Installation Manual.
