LIP-8040L User Guide
58
8.5 Push-To-Talk (PTT) Page
iPECS Phones can be assigned as a member of one or
more of the system’s nine Push-To-Talk (PTT) page
groups. Users separately log-in or log-out of any one or
all PTT groups to which the phone is assigned. Once
logged in, place or receive one-way page
announcements to/from other users who are logged in
to the same PTT group.
8.6 Wake-Up Alarm
iPECS su
pports an Alarm clock for each station in the
system. The alarm clock can be set to repeat daily or
as a one-time alarm.
When responding to the alarm by lifting the handset,
BGM will be provided.
To log-in to a PTT group:
 Dial #0(iPECS-LIK)/538(iPECS-MG),
 Dial the desired PTT group number (1-9 or 0 for all
groups),
To log-out of the PTT group(s):
 Dial #0(iPECS-LIK)/538(iPECS-MG), the PTT Log-in/out
code,
 Press the * key.
To place a page announcement to the active PTT group:
 Press and hold the
PTT Flex button,

After confirmation tone, make page announcement.
To set the Wake Up Alarm clock:
 Press
TRANS/PGM,
 Dial 41(iPECS-LIK)/13(iPECS-MG) (Alarm Clock code),
 Dial 2-digit hour and minute (hh/mm) for alerting,
 For a daily (repeating alarm), press #,
 Press
HOLD/SAVE.
To erase Wake-Up:
 Press
TRANS/PGM,
 Dial 42(iPECS-LIK)/14(iPECS-MG) (Alarm Clock delete
code),
 Press HOLD/SAVE.
