Basic Functions
117
Basic
Functions
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
05
V1 input monitor
V1 Monitor
0.00
0.00–10.00 V
V
06
V1 polarity options
V1 Polarity
1
Bipolar
0–1
-
12
V1 minimum input
voltage
V1- volt x1
0.00
0.00–10.00 V
V
13
V1 output at
minimum voltage (%)
V1- Perc y1
0.00
-100.00–0.00%
%
14
V1 maximum input
voltage
V1- Volt x2
-10.00
-10.00–0.00 V
V
15
V1 output at
maximum voltage (%)
V1- Perc y2
-100.00
-100.00–0.00%
%
Rotational Directions for Different Voltage Inputs
Command /
Voltage Input
Input voltage
0–10 V
-10–0 V
FWD
Forward
Reverse
REV
Reverse
Forward
10–10 V Voltage Input Setting Details
Code
Description
IN-12 V1- volt x1–
IN-15 V1- Perc y2
Sets the gradient level and offset value of the output frequency in relation to
the input voltage. These codes are displayed only when IN-06 is set to “1
(bipolar)”.
As an example, if the minimum input voltage (at V1) is set to “-2 (V)” with 10%
output ratio, and the maximum voltage is set to “-8 (V)” with an 80% output
ratio, the output frequency will vary within the range of 6–48 Hz.
