LSIS SV-IS7 User Manual

Basic Functions
119
Basic
Functions
6.1.3.3 Setting a Reference Frequency using Input Current (I1)
You can set and modify a frequency reference using input current at the I1 terminal. Set DRV-
07 (Frequency reference source) to “3 (I1)” and apply an input current of 0–20 mA to I1.
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
DRV
07
Frequency reference
source
Freq Ref Src
3
I1
0–9
-
IN
01
Frequency at
maximum analog
input
Freq at 100%
60.00
0–max.
frequency
Hz
20
I1 input monitor
I1 Monitor
0.00
0.00–20.00
mA
22
I1 input filter time
constant
I1 Filter
10
0–10000
ms
23
I1 minimum input
current
I1 Curr x1
4.00
0.00–20.00
mA
24
I1 output at
minimum current (%)
I1 Perc y1
0.00
0–100
%
25
I1 maximum input
current
I1 Curr x2
20.00
4.00–20.00
mA
26
I1 output at
maximum current (%)
I1 Perc y2
100.00
0.00–100.00
%
31
I1 rotation direction
options
I1 Inverting
0
No
0–1
-
32
I1 quantizing level
I1
Quantizing
0.04
0.00*, 0.04–
10.00
%
* Quantizing is disabled if “0” is selected.
