• The 0.75–22kW (200 V/400 V) models are provided with a built-in dynamic braking unit.
Installation of additional dynamic braking units is not necessary for these models.
• Refer to the instruction manual provided by the manufacturer before installing a dynamic
braking unit. There may be specification changes that are not reflected in the table provided
with this manual.
• For detailed specifications of type A DB units, such as resistance/wattage/braking torque/%ED,
refer to the table in 9.1.6 DB Resistors on page 217. For type B and type C DB units, refer to the
instruction manual provided by the manufacturer.
