Page 192
REPAIR INSTRUCTIONS, PART 1
190
Figure 190 — Counterbore Ledge Tool Installation
1. Cutter Plate Holder
2. T-Handle
3. Capscrews, M16 x 2 x 90
4. Special Washers
5. Upper Depth-Set Collar
6. Lower Thumbscrew
7. Oil Fill Tube
8. Main Housing
9. Hold-Down Capscrews
10. Cutter Bit Adjuster
11. Cutter Bit
12. Hold-Down Cap
13. Cutter Plate
14. Cylinder Block
15. Main Shaft
16. Lower Depth-Set Collar
17. Upper Thumbscrew
18. Hex Key Wrench
5-111.bk Page 192 Monday, July 10, 2006 2:26 PM
