REPAIR INSTRUCTIONS, PART 1
Page 321
371
Figure 371 — Nozzle Holder Gasket Installation
2. Lubricate the surface of the nozzle holder
with clean engine oil and install the top
O-ring on the holder.
3. Thread injection nozzle puller J 37093 into
the top of nozzle holder as shown in
Figure 372.
372
Figure 372 — Puller Application
1. Washer 2. Nozzle
1. Nozzle Holder Puller
J 37093
2. Nozzle Holder
5-111.bk Page 321 Monday, July 10, 2006 2:26 PM
