REPAIR INSTRUCTIONS, PART 1
Page 341
401
Figure 401 — EGR and EUP Heat Shield Installation
1. Outer EUP Heat Shields
2. Inner EUP Heat Shield (Two Piece)
3. EGR Valve Heat Shield
4. Cylinder Heads
5. Exhaust Manifold
