Page 398
REPAIR INSTRUCTIONS, PART 2
477
Figure 477 — Water Pump Installation
1. Engine Lifting Bracket
2. Threaded Inserts and Upper Mounting Bolts
3. Stiffening Bracket Forward Mount
4. Mid-Position Mounting Bolts
5. Low-Position Mounting Bolts
6. Water Pump Assembly (Housing and Cartridge)
7. Water Pump Stiffening Bracket
8. Stiffening Bracket Rear Mount
9. Water Pump Cartridge
5-111.bk Page 398 Monday, July 10, 2006 2:26 PM
