SPECIFICATIONS
Page 481
OIL PUMP
Oil Pump Cover-to-Housing Screw 15 20
Oil Pump-to-Cylinder Block Mounting Screw 40 55
Oil Pump Shaft Driven Gear Retaining Nut 60 81
Oil Pump Inlet Fitting-to-Oil Pump Housing Screw 35 47
Oil Pump Pressure Relief Valve Cap 80 108
PISTON COOLING
Piston Cooling Nozzle-to-Cylinder Block Screw 15 20
SENSORS (FOR DASH GAUGES)
Coolant Temp. (1/2 NPT, side mount on water manifold) 23 31
Oil Temp. (1/4 NPT, mount on oil filter pedestal) 18 24
Oil Temperature (1/2 NPT, side mount on oil pan) 23 31
SENSORS (V-MAC III)
Air Temperature (3/8 NPT) 18 24
Ambient Air Temperature (1/2 NPT) 23 31
Boost Air Temperature (M16 x 2) 28 38
Coolant Temperature (3/8 NPT, rear mount on water manifold) 23 31
Fuel Temperature (3/8 NPT) 23 31
Oil Pressure (1/8 NPT) 13.5 18
Oil Temperature (3/8 NPT) Optional 23 31
Engine Speed and Position (flywheel housing and engine front cover) 7 10
Turbocharger Wheel-Speed Sensor 9 12
TIMING GEAR COVER (ENGINE FRONT COVER)
Breather Mounting Screws 15 20
Front Engine Mounting Bracket-to-Crossmember 180 245
Timing Cover and Front Support Bracket-to-Cylinder Block Screw 70 95
Timing Cover-to-Cylinder Block Screw 40 55
TURBO AND EXHAUST MANIFOLD
Turbo-to-Exhaust Manifold Stud Nut 100 136
Turbo Oil Inlet Tube-to-Turbo Screw 15 20
Turbo Oil Drain Tube-to-Turbo Screw 15 20
Exhaust Manifold-to-Cylinder Head Stud (Install with Loctite
®
272. See “NOTE
4 — EXHAUST MANIFOLD TORQUING” on page 488.)
20 (Dry) 27 (Dry)
Exhaust Manifold-to-Cylinder Head Stud Nut (12 mm full threaded stud, See
“NOTE 4 — EXHAUST MANIFOLD TORQUING” on page 488.)
100 136
Turbo Drain-to-Cylinder Block Screw 40 55
Turbo Center Bearing-to-Turbo Housing 30 41
Turbo Compressor Housing Clamp Band Retaining Nut 105 lb-in 11.9
Fastener Name
Torque
Lb-Ft N폷m
5-111.bk Page 481 Monday, July 10, 2006 2:26 PM
