Page 482
SPECIFICATIONS
VALVE ROCKER ARM
Valve Rocker Arm Bracket-to-Cylinder Head Screw 40 55
Valve Rocker Arm Adjusting Screw Jam Nut 45 61
Valve Yoke Adjusting Screw Jam Nut (See “NOTE 5 — VALVE YOKE
SETTING” on page 489.)
33 45
Valve Rocker Arm Shaft Locating Screw:
Non-Brake/J-Tech™ 23 31
PowerLeash™ 23 31
VTG CONTROL VALVE
VTG Control Valve Mounting Screw 15 20
VTG Control Valve Air Fitting Jam Nut 19 25.8
WATER MANIFOLD AND WATER PUMP
Water Manifold-to-Cylinder Head Screw 40 55
Water Pump Inlet Tube Screw 40 55
Water Pump Housing-to-Cylinder Block Screw:
M12 69 94
M10 40 55
Water Pump Slotted Insert (M27) 50 in-lb 5.6
Water Pump Stiffening Bracket (8M Flanged Nut) 20 27
Water Pump Cartridge to Water Pump Housing Screw 17 23
MISCELLANEOUS
Air Conditioner Compressor Mounting Bracket-to-Engine Block 69 94
Air Conditioner Compressor Mounting Bracket-to-Timing Cover 48 68
Air Conditioner Compressor-to-Radiator Support 17 23
Alternator Mounting Stud Nut 70 95
Battery Cable (stud type) 10–15 14–20
Coolant Conditioner Adapter Mounting Screw 15 20
Hydraulic Steering Pump-to-Engine Front Cover Stud Nut 40 55
Idler Gear Hub-to-Cylinder Block Screw 70 95
Oil Dipstick Hole Plug (M20 tapered thread) 20 27
Oil Dipstick Hole Plug (M16 x 1.5) 20 27
Oil Dipstick Guide Tube Compression Nut (at oil pan) 20 27
Oil Dipstick Guide Tube Screw (at Filter Bracket) 24 lb-in 3
Radiator Mount-to-Front Crossmember 85 115
Radiator Tie Bar-to-Radiator Side Bracket 30 41
Starter Motor Wiring Harness:
1/2 x 13 22.5 30.5
#10–32 23 lb-in 2.6
Fastener Name
Torque
Lb-Ft N폷m
5-111.bk Page 482 Monday, July 10, 2006 2:26 PM
