Figure 35 — ASET™ AC Engine Sensors (Right Side)
1. VTG Wheel-Speed Sensor (in Bearing Housing)
2. VTG Position Sensor
3. Connector-to-Fan Speed Sensor
4. To Chassis-Mounted Compressor Discharge Temperature
Sensor
5. Engine Position Sensor
6. Fuel Temperature Sensor
