IGNITION
90-857046R1 NOVEMBER 2001 Page 2A-31
Crank Position Sensor Removal and Installation
1. Disconnect sensor from wiring harness.
2. Remove sensor mounting screws.
3. Reverse steps for installation.
a
b
c
a-Crank Position Sensor
b-Harness Connector
c-Screw (2) M5x16
Crank Position Sensor Mounting Screw Torque
45 lb. in. (5 N·m)
