IGNITION
Page 2A-24 90-857046R1 NOVEMBER 2001
Installation
1. Place flywheel key into slot.
2. Install flywheel. Apply oil to threads on crankshaft.
3. Install washer and nut.
4. Hold flywheel using flywheel holder (91-83163M) and tighten nut to the specified torque.
b
a
91-83163M
c
d
e
f
a-Key
b-Flywheel
c-Washer
d-Nut
e-Torque Wrench (with 30mm socket)
f-Flywheel Holder (91-83163M)
Flywheel Nut Torque
116 lb. ft. (157 N·m)
