MAINTENANCE
90-857046R1 NOVEMBER 2001 Page 1B-9
Lubrication Points
Lubricate Point 1 with Anti-Corrosion Grease or 2-4-C Marine Lubricant with Teflon.
1. Propeller Shaft – Refer to Propeller Replacement for removal and installation of the pro-
peller. Coat the entire propeller shaft with lubricant to prevent the propeller hub from cor-
roding and seizing to the shaft.
1
Lubricate Points 2 thru 6 with 2-4-C Marine Lubricant with Teflon or Special Lubricant 101.
2. Swivel Bracket – Lubricate through fitting.
3. Tilt Support Lever – Lubricate through fitting.
4. Tilt Tube – Lubricate through fitting.
4
2
3
To Next Page
