TILLER HANDLE
Page 7B-4 90-857046R1 NOVEMBER 2001
Tiller Handle Assembly Removal
1. Remove lower cowl.
a
b
a-Screws-M6x30 (6)
b-Screw-M6x60
2. Remove shift handle.
a
b
c
a-Shift Handle
b-Bushing
c-Screw-M8x35
